Basic Info.
Product Description
| Model | RT-S2516 |
| working area | 1600*2500MM |
| Machine size | 3450×2300×1250MM |
| Rated power | 9kw |
| Fixed model | Flated working table |
| Multifunctional head | Swiss imported knife: with vibration full cutting, vibration half cutting and cursor location function. |
| Safety device | Using infrared sensors, responsive, safe and reliable. |
| translational velocity | 800-1200mm/s |
| Cutting thickness | 200-800mm/s(according to different cutting materials) |
| Cutting materials | Leather, all kinds of clothing flexible material, Sponge composite leather, PVC, soft glass, Silicon, rubber |
| Repeated accuracy | ≤0.1mm |
| Transmission system | imported(Digital servo motor, linear guide, synchronous belt, ball screw) |
| Instruction system | HP-GL compatible format |
| Voltage | 380V±10% |
| Other configuration | Japanese Yaskawa servo motor,Germany imported conveyor belt, vacuum table, auto feeding, Taiwan Hiwin rail, 7.5kw vacuum pump |
Product Details
REALTOP CNC is a well-known CNC equipment manufacturer with more than 15 years machine production experience. We created "REALTOP" brand, and mainly engaged in the research and development, production, marketing and services of Laser Engraving Machine, Laser Cutting Machine, Laser Marking Machine, Digital Cutting Machine, CNC Router, etc.
REALTOP has gained CE certificate. Company successfully produce REALTOP series products of more than 50 sorts, which enjoy good reputation and support. Excellent quality and fast service makes our products spread all over the world, such as Europe, Middle east, America, and South Asian, etc. Welcome you to REALTOP, we will share top machines and services together with word-wide customers.
1. Can it be used for the fabric industry?
Yes, our digital cutting machines can be widely used in fabric, cloth, pu leather and other flexible material industry.
2. What's the mas thickness of ur pneumatic cutting tool can cut?
Our digital cutting table can be installed with the pneumatic cutting tool, and this tool can cut up to 70 mm;
3. The work you wanna handle with this digital cutting machine(Engraving ?Cutting ?Or others?)
The digital cutting machines can do the job of cutting, creasing and marking.
4. Do you have the manual of fabric cutting machines?
Yes,we can provide manual,CD software and video to help you operate the machine expertly.
5. If we do not know how to use the cnc cutting machine,can you teach us?
Yes ,of course. We can offer you free training, and engineers available to service machinery training overseas if you would like to offer them business expenditure.
6.How about your guarantee period for the digital cutting table?
Twelve months for the whole machine and 3 months for consumables including laser tube, lens and mirrors.
