Basic Info.
Model NO.
DK7780
Movement Method
Linear Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Certification
GS, CE, ISO 9001
Condition
New
Weight (Kg)
2300
Screws Form
Ball Screw
Guide
Inlaid Steel Rails
Total Machine Power
2.5 Kw
Machine Type
High-Speed-Wedm
Dimension(L*W*H)
2400*2250*1650
Showroom Location
None
Wire Travel Speed
11.5 M/S
Warranty of Core Components
1 Year
Video Outgoing-Inspection
Provided
Marketing Type
Hot Product
Core Components
PLC, Engine, Bearing
Key Selling Points
Competitive Price
Applicable Industries
Farms, Food & Beverage Shops, Restaurant
CNC or Not
CNC
Transport Package
Plywood Packaging
Trademark
ANTISHICNC
Origin
China
HS Code
8461909000
Production Capacity
300 Piece/Pieces Per Month
Packaging & Delivery
Package Size
2700.00cm * 1900.00cm * 1900.00cm
Package Gross Weight
3000.000kg
Product Description
| Machine Model | Unit | DK7780 |
| Machine Type | - | CNC wire cutting machine |
| Guide | - | Inlaid steel rails |
| Screws Form | - | Ball screw |
| Table size | mm | 1050*1400 |
| Table travel | mm | 800*1000 |
| Max. cutting thickness (height adjustable) | mm | 500 |
| Total machine power | kw | 2.5 |
| Machining Surface Roughness | μm | Ra≤2. 5 |
| Max. cutting speed | m²/h | 8000-10000 |
| Max. cutting taper | mm | ±6°/80mm |
| Molybdenum wire diameter | m | Φ0.13-Φ0.20 |
| Wire travel speed | m/s | 11.5 |
| Min. feed increment | mm | 0.001 |
| Pulse width adjustable range | μs | 15-150 |
| Max. power consumption | KVA | ≤1 |
| Motor type | - | Reactive Stepper Motor |
| Inverter speed regulation | m/s | 1~12m/s |
| Machine protection | - | Environmental protection cover |
| Motion axis motion resolution | mm | 0.001mm |
| U, V axis travel | mm | ±35×±35mm |
| Control Method | - | 4-axis linkage |
| Large load capacity | kg | 1000kg |
| Production Criteria (Acceptance Criteria) | - | GB7926-87 |
| Machine dimensions | mm | 1800*1400*1700 |
| Machine weight | kg | 6000 |
