Basic Info.
Production Capacity
100~150
Product Description
| GA-K50 | GA-K80 | GA-P60 | GA-P90 | |
| CUTTING HEIGHT mm | 50 | 80 | 60 | 90 |
| CUTTING AREA mm | 1800*1800(W2200) | 1800*1800(W2200) | 1800*1800(W2200) | 1800*1800(W2200) |
| BLADE SPEC. mm | 2*7 | 2.4*8.5 | 2*7 | 2.4*8.5 |
| CUTTING SPEED m/min | 50 | 50 | 80 | 80 |
| MAX ACCELERATION m/s2 | 5 | 5 | 8 | 8 |
| VIBRATION FREQUENCY rpm | 3600 | 3600 | 6000 | 6000 |
| POWER CONSUMPTION kw | 10 | 10 | 12 | 12 |
| MOBILE RAIL | Optional | |||
| SINGLE DRILL BIT | Optional | |||
| CUTTER COOLING | Optional | |||
| CUTTER DEVIATION CORRECTION | Standard | |||
| DIMENSION L&W mm | 4927*2230 | |||
| WORK PLATFORM mm | 800~900 | |||
| WEIGHT kg | 3800~4200 | |||
| VOLTAGE v, hz | 3P/N/PE, AC 380/50 | |||
| POWER kw | 28 | 30 | ||
| AIR FLOW nl/min | 160 | |||
| COMPRESSED AIR mpa | 0.7 | |||
| NOISE LEVEL db | <73 | |||
| CAD COMPATIBILITY | Culfile, ISO6983, RS274D, DXF, PLA, PLX etc | |||
| OPERATION SYSTEM | WINDOWS | |||
| MAX VACUUM kpa | -22 | |||
