Basic Info.
Power
30kw
Voltage
380V 50/60Hz
Machine Type
High Pressure PU Foaming Machine
Material
Isocyanate and Polyol(ISO and Pol)
Flow Rate
10-5000g/S
Application
PU Products
Transport Package
Plywood Case Packing
Specification
L4200 x W2000 x H2900mm
Trademark
Lingxin
Origin
China
HS Code
8477409000
Production Capacity
20 Sets/Month
Product Description
Technical Parameter:
Injection output: 2-5000g/s
Material tank volume: 30L-500L
Mixing ratio range: 100:28~100
Mixing head: 2800-5000rpm, forced dynamic mixing
Compressed air needed: dry, oil free, P:0.6-0.8MPa Q:600NL/min(customer-owned)
Nitrogen requirement: P:0.05MPa Q:600NL/min(customer-owned)
Temperature control system: heat:2×3KW
Input power: three-phase five-wire 380V 50HZ Other power customizable
Rated power: 8KW-12KW
Color( customizable): White/Red/Blue
Weight: 2000Kg
Dimension: 4200(L)*2000(W)*2900(H)mm
Equipment Overview:
PU foaming machines have wide application in the market, which have features of economy and convenient operation and maintenance,etc. The machines can be customized according to customers' requirement for various output and mixing ratio.
Application Cases :
Pillow, chair, seat cushion,wheel, crown molding, wall panel, steering wheel, bumper, integral skin, fast rebound, slow rebound, toys, knee pad, shoulder pad, fitness equipment, thermal insulation material filling, bicycle cushion, car cushion, hard foaming, refrigerator material, medical appliance, insole etc.
Our company:
Certificate:
Welcome to contact with us /send inquiry for more details of machines. We will reply you ASAP. Thanks.
