Basic Info.
Model NO.
IBR-ZTRFM
Customized
Customized
Usage
Roof, Wall, Floor
Transmission Method
Hydraulic Pressure
Speed
12m/Min
Coil Thickness
0.3-0.8mm
D.Shaft
80mm
Main Frame
350h
Power
9kw
Weight
6.5t
Thickness of Material
0.3-0.8mm
Dimension
7500X1500X1910mm
Voltage
380V 3phase 50Hz
Material of Roller
High Grade 45# Forged Steel Plated with Hard Chrom
Material of Cutting
Cr12 Mould Steel with Quenched Treatment
Workers
1-2 Only
Transport Package
Container
Specification
40ft
Trademark
GEIT-ZTRFM
Origin
China
HS Code
8455221000
Production Capacity
200sets/Year
Packaging & Delivery
Package Size
500.00cm * 150.00cm * 150.00cm
Package Gross Weight
1000.000kg
Product Description
IBR metal roll forming machine zinc color steel tile roofing sheet machines China machinery
IBR is widely used in the roofing industry and a common product used in roofing applications from industrial,commercial to residential applications.
It has become a household name in the South African building industry. The IBR's deep, broad flute design offers first-rate drainage abilities with ideal weight versus load/span characteristics. IBR can be factory Cranked, Curved and Bullnosed to various radii depending on customer's requirements.
Because of price pressure of the material used to manufacture, this product is getting thinner and harder requiring these IBR Rollforming machines to be specially designed to produce and ensure a good quality finished product. It can also be noted that the machines are often required to run 915mm material as well or even 1225mm wide coil.
| No. | IBR roll forming machine | |
| 1 | Suitable material | Color steel sheet ,galvanized steel sheet, aluminium sheet |
| 2 | Width of material | 1000mm or as need |
| 3 | Thickness of material | 0.3-0.8mm or as your needs |
| 4 | Working speed | 10-20m/min |
| 5 | Electrical control system | PLC control system |
| 6 | Shaft diameter | 80mm/85mm |
| 7 | Dimension | 7500x1500x1910mm |
| 8 | Weight | About 7 T |
| 9 | Voltage | 380V 3phase 50HZ or as the customer's requirements |
| 10 | Material of roller | High grade 45# forged steel plated with hard chrome plating |
| 11 | Material of cutting | Cr12 mould steel with quenched treatment |
| 12 | Working time | Can be 24 hours |
| 13 | Workers | 1-2 only |
GEIT GROUP is a professional manufacturer and exporter which is concerned with the design, development and production of cold roll forming machines.
The factory located in Botou-Hebei, which focus on designing and manufacturing of different types cold roll forming machines.
