Product Description
SGW-680/550 plastic thermoforming machine adopts the most advanced plastic thermoforming technology and was developed to be a forming machine of high production efficiency. It is a combination of mechanical, electrical, and pneumatic components and the whole was controlled by micro PLC. The machine has a man-interface operation. Combines heating, forming, cutting & stacking into one process.
It is suitable for forming HIPS, PS, PVC, PET, PP sheet that can produce boxes, trays, fast food boxes, dishes, lids, cookies trays, mobile phone trays & other blister tray.
| Model | SGW-680/550 SGW-680/550 (4 Stations) |
| Max. Forming Area | 680*550mm |
| Max. Forming Depth | 100mm |
| Sheet Thickness Range | 0.15-1.2mm |
| Max. Sheet Width | 715mm |
| Air Pressure | 0.5-0.8Mpa |
| Speed | 500-1500 cycles/h |
| Heater Power | 38kw (Upper Heater) 29kw ( Lower Heater) |
| Cutting Pressure | 90tons |
| Upper Mold Table Stroke | 130mm |
| Lower Mold Table Stroke | 130mm |
| Max. Mold Depth | 110mm |
| Power | 3 Phases 380V/50HZ |
| Max. Hydraulic Pump Pressure | 16Mpa |
| Max. Cutting Length | 12000mm |
| Machine Total Power | 72kw |
| Overall Dimensions | 10580*2300*2200mm |
| Weight | 10000kg |
spare parts list
| 1 | Solenoid Valve | SMC SMC (Japan) |
| 2 | Panel | Siemens |
| 3 | PLC | Siemens |
| 4 | Control relay | |
| 5 | Cylinder | () YIDA COMPANY |
| 6 | Heating system | (, 3 ) Infrared Ceramic Heating Bricks(HUADA) |
| 7 | Servo-Motor for material feeding | () INVT |
| 8 | Servo-Motor for mould forming | () INVT |
| 9 | Miniature Circuit Breaker | |
| 10 | AC Contactor | |
| 11 | Oil-water separator | SMC() SMC (Japan) |
| 12 | SSR(solid state relay) | () Yangming(Taiwan) |
| 13 | Temperature Module | Hexin |
| 14 | Vacuum Pump | Beiker |
1. Q: What is the machine warranty?
A: One year.
2. Q: Does your machine with CE certificate?
A: Yes.
3. Q: What is the production time while placing an order?
A: About 35 days
4. Q: What is the delivery time?
A: Within 30 days after getting the payment.
5. Q: Can your company handle shipping for customers?
A: Yes. (Please provide us with your requested seaport and we can check the shipping charge and arrange to ship for your order)
6. Q: Does the packing strong?
A: Yes, of course! All of our export packings is with strong wooden pallets, all are confirmed to export packing standard.
7. Q: How about the after-sales service process?
A: When your machine has a problem, contact your sales and we will solve your problem soon as possible.
8. Q: Are you a manufacturer?
A: Yes, we are a manufacturer with 10-year experience and profession.
9. Q: Do you have a stock product to sell?
A: Our machine needs 20-30 days to manufacture, and there are many orders from China and foreign countries, so we need
custom one for you, and your order will be highly attentive to manufacture.
10. Q: Do you inspect the finished products?
A: Yes, we have a QC department, they will inspect the machine before shipping, to ensure there is nothing problem with the machine.
11. Q: What's the payment term?
A: T/T 30% in advance, the balance paid before delivery. We also accept payment via West Union and L/C. We are a professional
manufacturer since 2005. We believe our products will provide you with great business benefits and advantage.
